Fouled spark plugs, faulty ignition coils, and fuel injection problems lead to noticeable performance loss, rough idling, and significant power reduction. These malfunctions occur regularly but can be recognised and resolved in a timely manner with the right knowledge. Read on to discover which symptoms are warning signs and what you can do about them.
Recognisable symptoms of ignition and injection problems
When spark plugs, ignition coils, or the fuel injection system are not functioning correctly, you will immediately notice it in your engine’s behaviour. The most common signs are:
- Engine shakes when idling or at low revs, often accompanied by a check engine light
- Hesitation or loss of power during acceleration, especially above 3000 rpm
- Starting difficulties with a cold engine, particularly in the morning
- Increased fuel consumption and sometimes black smoke from the exhaust
- Uneven idling or sudden malfunctions while driving
These complaints can occur individually, but often you will see multiple symptoms at the same time. In many models, such as the Ford Focus with petrol engines, these are known problems that occur over time. Timely recognition of these symptoms prevents further engine damage.
‘ When spark plugs have too much carbon build-up or the electrodes are too far apart, you get misfires and loss of power. ’
What are spark plugs and why do they fail
Spark plugs generate the spark that ignites the air and fuel mixture in the cylinder. They wear out due to high temperatures and constant pressure. Copper spark plugs typically last around 30,000 kilometres, while iridium or platinum variants can last up to 100,000 kilometres.
Contamination, oil leaks, or an incorrect gap between the electrodes accelerate wear. The ideal gap is between 1.0 and 1.3 millimetres. When spark plugs have too much carbon build-up or the electrodes are too far apart, you get misfires and loss of power.
Ignition coils and their role in the ignition system
Ignition coils convert the voltage from the battery into the high voltage required for the spark in the spark plug. A faulty ignition coil causes one or more cylinders to malfunction, resulting in engine hesitation and a clearly noticeable vibration.
Ignition coils often fail due to heat and moisture. Most coils fail between 80,000 and 120,000 kilometres. When one ignition coil fails, it is advisable to replace all of them at the same time. This prevents you from encountering the same problem again in a short period and saves labour costs.
Fuel injector problems and their consequences
Fuel injection regulates how much fuel is sprayed into the engine. Clogged or leaking injectors lead to an incorrect air-fuel mixture, resulting in rough engine running, stuttering during acceleration, or even sudden stalling.
Carbon build-up in injectors is common in cars primarily driven for short distances or those filled with lower-quality fuel. Leaking O-rings in injectors cause overfilling of the cylinders. These problems are more sensitive in direct injection systems than in older indirect systems.
What does fuel injection repair cost
Professional cleaning of injectors costs between 100 and 300 euros. For faulty injectors or leaking seals, garages charge 300 to 600 euros, including labour. Preventive use of fuel additives helps prevent contamination but cannot always resolve severe blockages.
‘ Always check the car manufacturer’s recommendations. ’
How often should you replace spark plugs
The replacement interval depends on the type of spark plug and your driving habits. For regular copper spark plugs, an interval of approximately 30,000 kilometres applies. Iridium and platinum spark plugs last longer and can go 60,000 to 100,000 kilometres before replacement is needed.
Always check the car manufacturer’s recommendations. With intensive use, many short trips, or regular misfires, replacement may be needed sooner. Have spark plugs replaced by a specialist or do it yourself if you have experience with engine maintenance.
Recognising signs of bad ignition coils
When an ignition coil fails, you will notice specific symptoms. The engine noticeably hesitates during acceleration, and you will often see a check engine light on the dashboard. An OBD2 scanner – a device used to read fault codes from the engine computer – will show fault codes such as P0300 to P0304, indicating misfires in specific cylinders.
Another indication is a burning or chemical smell around the bonnet. Ignition coils get hot and can emit a typical odour when they fail. Swap coils between cylinders to test which one is faulty: if the fault code moves to another cylinder, you know the coil is the culprit.
How to test a MAF sensor
The MAF sensor, or Mass Air Flow sensor, measures how much air the engine draws in. A contaminated or faulty sensor sends incorrect information to the engine computer, leading to an incorrect air-fuel mixture. This results in poor idling, engine hesitation, and increased fuel consumption.
Test the MAF sensor by reading its values with an OBD2 scanner. With a stationary engine, the sensor should indicate 0 grams per second. When idling, a normal value is between 2 and 7 grams per second, depending on the engine size. Large deviations indicate a fault.
Carefully clean the sensor with a special MAF sensor cleaner. Do not use regular brake cleaner, as it can damage the sensitive element. If cleaning does not help, replacement is the only option.
‘ When injectors leak, fuel also flows into the cylinders while the engine is off. ’
Can poor fuel injection use a lot of fuel
Yes, faulty or leaking injectors cause significantly higher fuel consumption. When injectors leak, fuel also flows into the cylinders while the engine is off. With clogged injectors, the engine computer compensates by injecting for longer, which also leads to overconsumption.
Another cause is an incorrect air-fuel mixture due to contaminated injectors. The engine then receives too little oxygen or too much fuel, resulting in incomplete combustion. This is reflected in black smoke from the exhaust and sometimes even a noticeable fuel smell from the exhaust.
Diagnosis and testing of ignition and injection problems
A thorough diagnosis begins with an OBD2 scanner to read fault codes. Codes like P030x indicate misfires, while P0171 or P0174 point to a lean mixture. This information guides further checks.
Next, perform a visual inspection. Disconnect the ignition coils and examine the spark plugs. Wet spark plugs indicate oil leakage, while white deposits may point to coolant problems. Black, sooty spark plugs are the result of an overly rich mixture.
Measure the fuel pressure with a pressure gauge. Normally, the pressure is between 3 and 4 bar in most petrol engines. Too low pressure indicates a weak fuel pump or clogged filter. Too high pressure points to a faulty pressure regulator.
A compression test provides insight into the mechanical condition of the engine. When the compression drops below 10 bar per cylinder, it could indicate problems with valves or piston rings. This exacerbates the consequences of bad spark plugs or ignition coils.
Prevention and maintenance tips
Regular maintenance prevents many problems. Replace spark plugs according to the recommended intervals and preferably choose quality spark plugs from the original brand. When tightening, use a torque wrench and set it to 20 Nm to prevent damage.
Preferably fill up with 98 RON petrol instead of 95 RON. Higher octane ratings reduce carbon build-up and extend the lifespan of spark plugs and injectors. Replace the air filter every 20,000 kilometres to prevent contamination of the MAF sensor and injectors.
Regularly check the PCV valves – small valves that relieve excessive pressure in the engine block. Stuck PCV valves cause overpressure in the crankcase, leading to oil leaks and spark plug contamination. Lubricate ignition coils with dielectric grease to prevent moisture and oxidation.
‘ Discover more articles and become a better-informed car owner. ’
Learn more about car problems and maintenance
On the Carnews website, you will find comprehensive information about common car problems, maintenance tips, and practical solutions. Whether you want to know more about specific makes and models, or are looking for advice on repairs and diagnostics, you will find all the knowledge you need. Discover more articles and become a better-informed car owner.
Frequently asked questions
The most common symptoms include irregular or shaking idling and noticeable misfires, especially during acceleration. Additionally, loss of power, hesitation, or stuttering during acceleration, and increased fuel consumption often occur. Starting problems can also arise, particularly with a cold engine. Sometimes black smoke from the exhaust is visible due to incomplete combustion.
You can check the spark plugs by removing them one by one and examining the colour and condition of the electrode: light brown/grey is normal, while black soot, oil deposits, or melted/white tips indicate problems or wear. Also, check the electrode gap with a feeler gauge and compare it to the factory value (usually around 1.0–1.3 mm). For ignition coils, look for cracks in the housing, signs of arcing (black streaks), corrosion on the contacts, and test by swapping coils between cylinders to see if the misfire/fault code moves. If you notice deviations or moving fault codes during a visual inspection or after the swap test, then the respective spark plug or ignition coil needs replacing.
Faulty fuel injectors can deliver an incorrect amount or distribution of fuel into the cylinders, causing the engine to run irregularly and produce less power. Clogged or poorly atomising injectors often cause hesitation, misfires, and a noticeable loss of pulling power. Leaking injectors can lead to an overly rich mixture, black smoke, and fouled spark plugs. Both clogged and leaking injectors almost always result in higher fuel consumption and sometimes increased emissions.
Effective methods include: timely replacement of spark plugs according to factory specifications (preferably iridium/platinum, correct electrode gap, correct tightening torque) and always using quality parts. Keep the engine in good condition with regular air and fuel filter maintenance, and use clean, high-quality fuel to limit contamination and misfires. Protect ignition coils from heat and moisture (check for hairline cracks, use dielectric grease during installation, and ensure cables and connectors are not damaged or corroded). At the first symptoms of stuttering or misfires, seek immediate diagnosis (OBD readout, swap test) to prevent subsequent damage to coils and spark plugs.
While “performance” spark plugs (e.g., iridium or platinum) and reinforced ignition coils are available, they typically provide at most a slightly smoother running engine or better cold start for a standard engine, not a noticeable power gain. The greatest benefit comes from replacing worn or inferior parts with good quality OEM-spec spark plugs and coils. For tuned or heavily stressed engines, stronger coils and heat-resistant spark plugs can improve reliability and ignition reserve. However, do not expect a significant horsepower increase solely by upgrading these components.
