A stretched timing chain in the THP engine of the Peugeot 2008 causes misfires, tooth skipping and can lead to valve damage if it breaks. With this engine, the problem is no exception – it is a known defect. It occurs regularly in the 1.6‑litre EP6 engine with 140 to 173 hp. The cause lies in the combination of high thermal load from the turbo, hydraulic tensioners that fail when the wrong oil is used, and production issues in early model years. How do you prevent costly engine damage and what are the first warning signs that your chain is heading for trouble?
What is the problem with the THP engine?
The Peugeot 2008 with THP engine often suffers from a stretched timing chain. This turbo engine was developed in cooperation with BMW as part of the Prince engine family. The chain drives the camshafts and controls the timing between the valves and the pistons. When it stretches, too much play develops and the timing is thrown off. The chain can even skip teeth or, in the worst case, break, causing immediate valve damage.
The problem occurs mainly with the 1.6 EP6DT variant, which was fitted in the Peugeot 2008 between 2013 and 2020. Early versions of this engine had weak chains and tensioners. These versions were built before 2012. PSA later introduced improvements, but even later models remain prone to this problem if maintenance is incorrect or neglected.
How do I recognise a stretched timing chain in a Peugeot 2008?
The symptoms of a stretched chain are easy to recognise. When starting from cold, listen for rattling or ticking noises coming from the engine. These sounds are caused by the chain hitting the sprocket due to the excess play. If the engine rattles for longer than three seconds when starting, there is probably too much slack.
Other common symptoms are:
- Vibrations when accelerating or at higher revs
- Check Engine light with fault codes P0011 or P0016, indicating incorrect cam timing
- Unstable running of the engine at idle
- Loss of power or hesitant throttle response
Owners report that these symptoms often occur after 80,000 to 120,000 kilometres. With intensive use or poor maintenance, they can appear as early as 50,000 kilometres. Do not ignore these warning signs, because with further stretching the chain can jump. The engine is then often completely destroyed by valves and pistons colliding.
Why does the chain stretch?
The causes of a stretched timing chain are varied. They are mainly related to the load on the engine and the quality of maintenance. The THP engine uses a turbo, which puts the engine under heavy thermal stress. These high temperatures accelerate wear of the chain and the hydraulic tensioners.
The hydraulic chain tensioner works on oil pressure. If the wrong or old oil is used, this system fails and play develops. PSA prescribes the use of oil with specification 0W‑30 or 5W‑30, approved according to a PSA standard. Oil such as Total Quartz Ineo ECS meets these requirements. If other oil is used or replacement intervals are too long, wear increases rapidly.
Production problems also played a role. Early EP6 engines had weaker chains and tensioners that failed more quickly. After 2012 PSA introduced improvements, which made later engines somewhat more reliable. Even so, frequent and careful maintenance remains essential.
What are the consequences of a broken chain in THP engines?
A broken timing chain in the THP engine always causes serious engine damage. That is because the engine is an interference engine. In this type of engine, valves and pistons use the same space in the cylinder at different moments in the cycle. When the chain breaks, the drive to the camshafts stops immediately. The valves remain in the wrong position while the pistons continue to move. This leads to collisions between valves and pistons.
The consequences are:
- Bent valves
- Broken valves
- Damaged pistons
- Damaged cylinder walls
- Damage to the cylinder head
- Possible damage to the crankshaft
- Possible damage to connecting rods
The repair costs for this kind of engine damage quickly rise to 3,000 euros or more. In many cases it is no longer economically viable to repair the engine and the decision is made to replace the complete engine or even the car.
‘ This is a considerable amount, but much lower than the cost of engine damage after a break. ’
When should I replace the timing chain of my Peugeot 2008?
Peugeot does not specify a fixed replacement interval for the timing chain in the service manual. The manufacturer assumes that the chain will last the lifetime of the engine. In practice, however, this is not realistic for the THP engine. Preventive replacement at around 100,000 to 120,000 kilometres is strongly recommended, especially for cars built before 2016.
If you hear rattling noises or see fault codes related to cam timing, replace the chain immediately. Do not wait until the symptoms get worse. When replacing, it is wise to renew other parts at the same time. Also replace the tensioners, guides and the sprocket. This prevents other worn parts from causing new problems later on.
The cost of a complete replacement kit is between 400 and 700 euros for the parts. Labour at a specialist garage adds another 400 to 800 euros, bringing the total cost to 800 to 1,500 euros. This is a considerable amount, but much lower than the cost of engine damage after a break.
How can you prevent problems with the timing chain?
Regular maintenance reduces the risk of a stretched chain. Replace the engine oil every 10,000 to 15,000 kilometres, even if the manufacturer allows longer intervals. Always use oil that meets the PSA specification. The wrong oil damages the hydraulic tensioners and accelerates chain wear.
At every cold start, listen for rattling noises. If the rattling lasts longer than three seconds, have the engine checked immediately at a garage with Peugeot diagnostic systems such as Lexia or PP2000. These systems can read fault codes that point to cam timing issues.
Use fuel with an octane rating of at least 98 RON. This helps prevent detonation, which increases the thermal load on the engine. Also avoid very short trips, where the engine does not reach full operating temperature. Regular longer journeys help to lubricate the engine properly and promote the burning off of oil residues.
When replacing the chain, you can opt for an improved kit. Kits with part number 1223 3A or equivalent sets often offer better durability than the original parts from early model years.
Repair by a specialist
Replacing a timing chain is highly technical work that requires specialist knowledge. Go to a garage that has experience with Peugeot engines and has the right diagnostic equipment. Doing it yourself is only advisable if you have sufficient technical experience and the correct tools.
Early Peugeot 2008 THP models were sometimes covered by warranty or a recall. Check with the dealer whether your car qualifies for a free repair based on the VIN (Vehicle Identification Number, the unique chassis number of your car). PSA has issued several bulletins about this problem, meaning some owners were helped free of charge.
After replacement, the engine often drives like new again. Owners report that rattling noises disappear immediately and the engine runs more smoothly. With correct maintenance, a Peugeot 2008 THP can cover more than 200,000 kilometres without problems.
‘ Discover more tips on maintenance, engine problems and practical solutions that help you avoid expensive repairs. ’
More information about car problems
On the Carnews website you will find clear information about common problems with various car brands and models. Discover more tips on maintenance, engine issues and practical solutions that help you avoid costly repairs. Have a look around and stay up to date with everything you need to know as a car enthusiast.
Frequently asked questions
Typical warning signs are a rattling or ticking noise when starting from cold and at idle, especially in the first few seconds after starting. The engine may run roughly, vibrate and pick up less cleanly when accelerating. Often the engine warning light will also come on, with fault codes such as P0011 or P0016 that indicate abnormal valve timing. In more serious cases you will notice clear loss of power and very rough running, which may point to advanced chain stretch.
The main causes are a weakly designed chain and tensioner system in early THP engines, high thermal load from the turbo, and oil change intervals that are too long or oil of the wrong specification. This leads to poor operation of the hydraulic chain tensioner and causes the chain to stretch. Always use the specified high‑quality engine oil and change it every 10,000–15,000 km instead of the maximum factory interval. Listen for rattling at cold start (lasting longer than a few seconds) and have the chain checked immediately if you notice it. Consider preventive replacement of the complete timing chain set at around 100,000–120,000 km to reduce the risk of serious engine damage.
A neglected stretched timing chain can cause the chain to jump or break, so that the pistons and valves hit each other and severe engine damage occurs, which may require a full engine rebuild. In such cases, repair costs for a Peugeot 2008 THP often rise to €3,000 or more. By comparison, timely replacement of the timing chain set usually costs around €800–€1,500 at a garage.
When starting from cold, listen for rattling or ticking noises around the timing chain side that last longer than 1–2 seconds, and also listen when idling warm for irregular running or metallic rattling. Use diagnostic equipment to check camshaft/crankshaft signals and read fault codes (including P0011, P0016) to see whether the timing is outside specification. Ask for a maintenance history showing regular oil changes (at most every 10,000–15,000 km, with the correct PSA specification) and whether the timing chain has already been replaced, and if so, with an improved kit. For a definitive assessment, a specialist can remove the rocker cover and measure chain play with the PSA measuring tool; play beyond the permitted limit indicates a worn or stretched chain.
