A stretched timing chain on the 1.8, 2.0 and 3.0 TFSI engines of the Audi A5 causes rattling noises, fault codes, rough running and loss of power. Defective tensioners and guide rails increase the risk of engine damage. Read on to find out how to recognise the symptoms and which steps you can take to avoid expensive repairs.
Which TFSI engines have chain problems
The timing chain problems mainly affect three engine types in the Audi A5. The 1.8 TFSI with engine codes CDHB, CABA, CABB, CDHA and CJEB is well known for this. The 2.0 TFSI with codes BUL, BGB, BWE, BPJ, CDNC, CDNB, CFKA and CDND also regularly suffers from this fault. Finally, the 3.0 TFSI with engine codes CGWA, CGWB, CGWD, CMUA, CRED, CTVA, CTJB and CJTC faces similar issues.
These engines were used in various Audi models between 2007 and 2016. Besides the A5 you will also find them in the A4, A6, A7, Q5 and Q7. The 1.8 and 2.0 TFSI turn out to be the biggest problem children.
Symptoms of a stretched timing chain
A rattling or clattering noise from the front of the engine is the first warning sign. This noise is especially noticeable during a cold start or when idling. Owners often describe it as a ‘diesel-like’ rattle that becomes louder and more frequent over time.
In addition, the following symptoms may occur:
- Illuminated engine management light with fault codes relating to timing or camshaft position
- Irregular idling
- Jerking or hesitation during acceleration
- Loss of power
- Misfiring engine
If you hear severe rattling it is wise to stop driving immediately. Continuing to drive can lead to the chain jumping a tooth, causing valves to collide with pistons and resulting in serious engine damage.
How timing chain problems arise in TFSI engines
The timing chain is driven by a hydraulic chain tensioner that operates on oil pressure. This tensioner is only active when the engine is running. Over time, the chain stretches due to normal wear. The tensioner can then no longer compensate for the slack.
A locking mechanism prevents the chain from going slack when the engine is switched off. In cases of extreme stretching this mechanism fails. As a result, the timing becomes misaligned and the valves can be damaged.
Other common defects that contribute to the problem are broken guide rails, worn sprockets and defective chain tensioners. Poor maintenance, such as old engine oil or irregular oil changes, accelerates the process. The factory chains often prove to be undersized for the high loads of these turbocharged engines.
When do the problems usually occur
In practice, the timing chain often stretches after 4 to 5 years or between 60,000 and 80,000 kilometres. Some owners report problems as early as 70,000 kilometres. Others have no complaints up to 100,000 kilometres or more. The degree of wear depends on several factors. Maintenance, driving style and the quality of the oil used all play a role.
What are the consequences of a broken timing chain
If the timing chain jumps a tooth, the valve timing is thrown off. Valves collide with pistons, leading to damage to both components. Such a situation requires replacement of the chain, tensioner, guides and sprockets. A full engine inspection is also necessary.
In more serious cases the cylinder head has to be overhauled. Some owners face costs of up to €4,500 at a dealer. At independent specialists prices range between €2,000 and €3,200 for preventive replacement, and between €3,000 and €5,000 when damage has already occurred. In extreme cases a complete engine swap is required.
‘ The damage that occurs when the chain jumps can run up to €4,500 or more. ’
How to prevent timing chain problems in your Audi A5
Regular servicing forms the basis of prevention. Change the engine oil every 10,000 kilometres or once a year. Use oil with the correct specification, such as VW 504.00 or 507.00. Quality oil keeps the hydraulic tensioner operating smoothly and slows down wear on the chain.
Pay close attention to unusual noises from the engine. At the first sign of rattling it is wise to have the car read with an OBD scanner. Early replacement costs between €2,000 and €3,000 and prevents severe engine damage.
Preventive replacement or wait until problems appear
For owners of a 1.8 or 2.0 TFSI, preventive replacement is a serious consideration, especially when the car approaches 60,000 kilometres and there is no evidence of previous replacement. Preventive replacement costs between €2,000 and €3,000. The damage that occurs when the chain jumps can run up to €4,500 or more. The same risk applies to the 3.0 TFSI, although problems are slightly less common here.
What to look out for when replacing the timing chain
Choose a workshop with experience in TFSI engines. Specialists usually carry out this work in 2 to 3 days and have the right expertise to do the job correctly. Dealer prices are often higher but do not always offer added value.
Consider opting for modified chains and tensioners with stronger materials and better resistance to stretching during replacement. These upgrades prevent the problem from recurring after a few years. Ask for parts from reputable manufacturers that supply improved versions.
Buying a used Audi A5 TFSI
When buying a used A5 with a TFSI engine, checking the service history is important. Ask whether the timing chain has already been replaced and whether this was done with improved parts. Check the mileage and note the engine code. During the test drive, listen for rattling noises when starting and when idling.
Should you replace the timing chain as a preventive measure
For owners of a 1.8 TFSI or 2.0 TFSI, preventive replacement is a sensible choice, especially when the car reaches 70,000 kilometres without evidence of earlier replacement. Owners report that proactive replacement around 70,000 to 80,000 kilometres makes worry-free driving possible. The engine then remains reliable well beyond 150,000 kilometres.
The cost of preventive replacement is between €2,000 and €3,000. This investment prevents repair bills of €4,500 or more if the chain jumps and damages the engine. A similar recommendation applies to the 3.0 TFSI, although problems are slightly less frequent here.
‘ In some cases a complete engine swap is necessary, which can lead to costs in excess of €7,000. ’
What does timing chain replacement cost for different engines
The costs for replacing the timing chain vary per engine type and workshop. For the 1.8 TFSI, the price range at specialists is between €2,000 and €2,800. Dealers often charge €3,500 or more.
For the 2.0 TFSI, costs range between €2,200 and €3,200, depending on the parts chosen and the condition of the engine. For the 3.0 TFSI, prices are slightly higher, between €2,800 and €3,500, because this engine has more components.
When damage has already occurred to valves or pistons, costs can rise to €5,000 or more. In some cases a complete engine swap is necessary, which can lead to costs in excess of €7,000.
Find out more about Audi problems on Carnews
On the Carnews website you will find extensive information about common problems with various Audi models. The tips and experiences help you to recognise faults in good time. You will also learn which steps you can take to solve issues. Find out more and stay up to date with everything you need to know as an Audi owner.
Frequently asked questions
Typical symptoms are a rattling or clattering noise at the front of the engine, especially during a cold start or when idling. This is often accompanied by an illuminated engine warning light and fault codes relating to camshaft/timing issues. The engine may idle roughly, hesitate or jerk during acceleration. Loss of power or a misfiring engine is also regularly reported.
The TFSI engine codes in the Audi A5 that are most prone to timing chain problems are mainly the 1.8 TFSI (CDHB, CABA, CABB, CDHA, CJEB) and the 2.0 TFSI (BUL, BGB, BWE, BPJ, CDNC, CDNB, CFKA, CDND). The 3.0 TFSI engines (CGWA, CGWB, CGWD, CMUA, CRED, CTVA, CTJB, CJTC) are also susceptible, but the 1.8 and 2.0 TFSI are considered the biggest problem cases.
You can extend the service life of the timing chain by changing the oil far more frequently than prescribed (preferably every 10,000 km or annually) using the correct VW 504.00/507.00 specification and only high-quality oil. Keep a close ear out for early symptoms such as rattling noises during a cold start, irregular idling or fault codes, and have the chain checked/read out immediately if you notice these. Consider having a modified chain and tensioner kit fitted preventively by a TFSI specialist, especially around 60,000–80,000 km or after 4–5 years. Have the car inspected periodically by an Audi/TFSI specialist, particularly when buying a used A5 TFSI, so that wear on the chain, guides and tensioner is detected in good time.
The costs of replacing the timing chain on an Audi A5 TFSI are generally around €2,000–€3,000 if there is no consequential damage yet. In the event of engine damage (chain jumped, damaged valves/head) costs can rise to around €3,000–€5,000. The repair itself usually takes 2–3 working days at a specialist workshop.
Audi has not introduced a broad, general recall for timing chain problems on the A5 TFSI like with some other known manufacturing defects. However, there are known cases where dealers or importers have contributed (partially) to repair costs as a goodwill gesture, especially for relatively young cars with a demonstrably good service history. This goodwill is highly dependent on factors such as age, mileage, maintenance history and dealer relationship, and is therefore not a fixed, legally enforceable scheme. It is advisable, in the event of a specific problem, always to first ask the Audi dealer and/or importer about possible goodwill options.
