A stretched timing chain in the Volkswagen Touran causes rattling noises when starting and can lead to timing shift with serious engine damage as a result. This problem often appears after just four to five years and mainly affects the TSI petrol engines. Find out what you can do before it is too late.
Which VW Touran suffers from chain problems
The timing chain is a common problem with specific petrol engines in the Volkswagen Touran. The 1.2 TSI and 1.4 TSI both regularly show faults with the chain. Newer model years suffer less from these issues, but the defect is known in both engines.
The 1.2 TSI relatively often develops problems due to a faulty chain tensioner that causes the chain to stretch. Chain problems also occur with the 1.4 TSI, although they are less common after 2007. Both engines are fitted with a relatively thin timing chain that is prone to stretching.
‘ In practice, however, faults already occur regularly after four to five years from the production date. ’
Why does the chain rattle when starting from cold
The rattling noise is caused by a stretched timing chain. As a result, the valve timing gets out of balance. This problem arises because the chain tensioner fails and no longer keeps the chain tight enough.
The noise is most audible when starting from cold. At that moment, the engine oil is not yet up to temperature and the pressure-operated chain tensioner works less effectively. At increased engine speed between 2500 and 3000 rpm, the rattling noise can also occur.
The thin timing chain is theoretically maintenance-free and should last the lifetime of the car. In practice, however, faults already occur regularly after four to five years from the production date.
Recognisable symptoms of a faulty chain
A stretched timing chain gives various warning signs. Early recognition prevents serious engine damage. Watch out for the following symptoms:
- Rattling or knocking noise when starting, especially with a cold engine
- Engine warning light coming on with fault codes in the engine management
- Poor or irregular idling
- Loss of power, juddering or the engine holding back on revs
- Rattling from the engine at higher revs
These signals point to a chain with too much play. The valve timing is then no longer correct and the engine is not running in sync. This can lead to a shift in timing where valves and pistons can collide.
How is the problem diagnosed
During servicing, the timing tension can be checked by removing the timing cover. If the tensioner is already halfway extended, this is a clear sign that the chain has stretched. A garage can establish this quickly.
The camshaft adjuster can also play a role in the rattling noise. This makes diagnosis more complex, because it is not always immediately clear whether the chain, the tensioner or the camshaft adjuster is causing the problem. A full inspection is therefore essential.
‘ Replacing just the chain is not enough, because the tensioner is often the cause of the stretching. ’
What does it cost to replace the timing chain
Experts and garage owners recommend replacing the timing chain, chain tensioner and camshaft adjuster at the same time. This combined approach permanently solves the problem in around 90 per cent of cases.
The costs vary depending on the garage and the region. Replacing only the chain is not sufficient, because the tensioner is often the cause of the stretching. Including the camshaft adjuster in the repair prevents rattling noises from returning again after a short period.
The small oil pump chain with usually 54 teeth generally does not need to be replaced. This saves on the overall repair cost.
Can I keep driving with a rattling chain
Continuing to drive with a rattling chain is unwise. The noise indicates a stretched chain that can slacken further at any moment. If the timing shifts completely, valves and pistons can collide. This leads to severe engine damage.
The repair costs of a damaged engine are considerably higher than the preventive replacement of the chain. If in doubt, have a diagnosis carried out at a specialist garage. This prevents unexpected breakdowns and high costs.
Buying tips for a used Touran
When buying a used Touran with a TSI engine, the service history is crucial. Always ask for the complete service book and check whether the timing chain and chain tensioner have already been replaced.
Experts recommend only buying TSI models when a complete service book can be shown. This should show that the timing chain, tensioner and preferably also the camshaft adjuster have been replaced. Also ask for replacement receipts and warranty documents.
Pay attention to the mileage and age of the vehicle. Older examples have a higher risk of chain problems. A car that is four to five years old without chain replacement calls for extra vigilance.
‘ Timely replacement prevents the engine from overheating. ’
Other known problems with TSI engines
Besides chain problems, TSI versions of the Touran also have other known faults. The 1.4 TSI regularly shows high oil consumption. Therefore, regularly check the oil level and top up when necessary.
Squealing noises from the water pump when accelerating also occur, especially in the 1.4 TSI. This indicates wear on the water pump, which will need to be replaced in due course. Timely replacement prevents the engine from overheating.
Preventive maintenance and advice
Preventive maintenance on the timing chain is not standardly possible, because the chain is in principle maintenance-free. However, it is sensible to have the chain checked during regular services, especially on cars from four years old.
Always use the correct engine oil and stick to the prescribed service intervals. This helps extend the lifespan of the chain and tensioner. Pay attention to unusual noises when starting and take these signals seriously.
If timing chain problems are suspected, it is advisable to have a diagnosis carried out immediately. Early intervention saves money and prevents severe engine damage. Do not postpone the check until the next service.
On the Carnews website you will find much more information about car problems, maintenance tips and experiences with different models. Discover more articles and increase your knowledge of automotive technology and maintenance.
Frequently asked questions
Rattling or knocking noise from the engine when starting (especially from cold) or around 2500–3000 rpm often points to a problem with the timing chain. In addition, an irregular or poorly idling engine and loss of power or juddering while driving can be symptoms. The engine warning light coming on (with corresponding fault codes in the engine management) can also indicate timing chain problems.
It is mainly the VW Touran with the 1.2 TSI and 1.4 TSI petrol engines that are most affected by timing chain problems. With the 1.4 TSI, the problems occur mainly in the older model years, roughly up to around 2007, and less frequently after that. In practice, however, all model years in which these 1.2 TSI and 1.4 TSI engine codes have been used can suffer from this chain problem.
The average costs for replacing a faulty timing chain on a VW Touran are usually around €800 to €1,500, depending on the garage, engine variant and whether the chain tensioner and camshaft adjuster are also replaced at the same time. The repair itself usually takes 1 to 2 working days.
Yes, owners can use engine oil with the correct specification as a preventive measure and change it on time (preferably more often than the factory interval) to limit wear on the chain and tensioner. During servicing, have the car regularly checked for rattling noises when starting from cold and, if necessary, have the chain tensioner/chain inspected visually. At early symptoms (brief rattling on start-up, fault codes, irregular running), it is sensible to have the chain and chain tensioner replaced as a preventive measure. When buying a used Touran, you can avoid problems by choosing only examples where the timing chain and chain tensioner have demonstrably already been replaced.
When buying a used VW Touran, pay particular attention to whether it has a TSI engine (1.2 or 1.4), as these are especially known for problems with a stretching timing chain and a failing chain tensioner. Check in the service history (invoices, service book) whether the timing chain, chain tensioner and possibly the camshaft adjuster have already been replaced preventively or recently. During a test drive and cold start, listen out for rattling/knocking noises from the engine, irregular idling and warning lights. Ideally, only buy a car with a demonstrably complete service history and, if in doubt, have a specialist perform a diagnosis.
