A properly functioning climate control system ensures comfort and safety in your car, but faults in the air conditioning system are annoying and can lead to inconsistent temperatures in the cabin. Often the problem is a low refrigerant level, defective clutches or a leaking condenser. The condenser is the component that cools the heated refrigerant and is usually located at the front of the car, behind the grille. These faults are not always clearly visible, but they are easy to recognise once you know what to look out for. In this article you will read how to recognise air-conditioning faults and what you can do about them.
Why isn’t the aircon blowing cold?
If the air conditioning is not blowing cold, the first thing you should check is the amount of refrigerant in the system. Too little refrigerant means the compressor cannot work effectively and the air will not be cooled sufficiently. This happens quite often. In most cases it is caused by a leak in the system.
Other causes are related to the compressor itself. The compressor is the heart of the air conditioning system and ensures the circulation of the refrigerant. If the compressor does not switch on, it is usually due to a defective clutch, a blown fuse or a fault in the relay. There are three possible causes. With models such as the Volvo V70 it is known that the compressor clutch can wear. This is the clutch that switches the compressor on and off. As a result, the aircon no longer cuts in.
A third possible cause is a blocked or dirty cabin filter. This is the interior filter that cleans the air in the car. This filter keeps dust and dirt out. If it becomes clogged, you get less airflow through the system. This does not directly cause warm air, but it does result in less cooling and poorer performance of the climate control system.
‘ Without this check the problem will remain and you will lose refrigerant again. ’
How do you check the refrigerant level?
Checking the refrigerant level is not something you can do yourself with standard tools. It requires special measuring equipment and knowledge of the air conditioning system. A garage can use a pressure gauge to determine whether there is enough refrigerant in the system. Low pressure indicates a leak or loss of refrigerant.
Some cars have a sight glass in the line, allowing you to see with the naked eye whether there are bubbles in the refrigerant. Bubbles often indicate a low level. However, not all models are fitted with this, which is why a professional inspection remains the most reliable method.
Many modern air conditioning systems contain a fluorescent tracer. With ultraviolet light you can then see where the system is leaking. This is an effective way to detect leaks before you add new refrigerant. Without this check the problem will remain and you will lose refrigerant again.
How much does it cost to fill the aircon with refrigerant?
Filling the air conditioning system with refrigerant costs between 50 and 100 euros, depending on the type of refrigerant and the amount required. Older cars often use R134a, while newer models use R1234yf. These are two different types of refrigerant. R1234yf is more expensive and more environmentally friendly than R134a.
If there is a leak, it must be repaired before the system can be refilled. Repairing a leak costs extra. The costs depend on the location and the severity of the leak. A leaking O-ring or hose connection is cheap to replace, but a broken condenser or evaporator can cost hundreds of euros. The evaporator is the component that allows the refrigerant to evaporate and in doing so cools the air before it flows into the cabin.
Many garages offer an air conditioning service, during which the system is checked, cleaned and refilled. This costs on average between 75 and 150 euros and prevents faults caused by neglecting the system. It is sensible to have this done every two to three years.
How do you recognise a leaking condenser?
You often recognise a leaking condenser by a gradual loss of cooling. At the start of the journey the air conditioning still works well, but after a while the air becomes less and less cold. This is because the refrigerant is slowly leaking away and the pressure in the system is falling.
The condenser is usually located at the front of the car, behind the grille. Because of this location it is sensitive to stone chips, rust and damage. If you see visible damage, corrosion or oil stains around the condenser, there is a good chance there is a leak. Oil and refrigerant mix in the system, so oil stains are a clear sign.
With a UV light inspection you can see exactly where the leak is. This is especially useful if the leak is not directly visible. Some owners also notice a strange smell when the air conditioning is on, which may indicate a leak or mould growth in the system. A professional inspection provides clarity.
‘ A diagnosis with a scan tool helps to determine the exact cause. ’
Faults in the climate control: inconsistent temperatures
If the climate control does not operate steadily and the temperature in the cabin varies unpredictably, the cause is often a defective sensor. The interior temperature sensor is the car’s internal temperature sensor. It measures the actual temperature in the car and controls the system to reach the set temperature. If this sensor is defective, the system receives incorrect information and responds illogically.
A faulty temperature flap can also cause problems. This flap regulates how much warm and cold air is mixed before it flows into the cabin. If the flap is stuck or does not respond properly, you will alternately get air that is too warm or too cold, regardless of the setting on the dashboard.
Electrical faults such as a blown fuse, defective relay or poor plug connections can also lead to inconsistent operation. This is especially the case with models with automatic climate control. This is a system that automatically controls the temperature in the car based on the set value. Multiple components are then controlled electronically. A diagnosis with a scan tool helps to determine the exact cause. This is a diagnostic device that reads fault codes from the car.
Is air conditioning repair expensive?
The cost of air conditioning repair varies greatly depending on the nature of the fault. Minor repairs such as replacing a fuse, relay or O-ring cost between 50 and 150 euros. These are often quick jobs that do not require major work.
Major repairs such as replacing a compressor, condenser or evaporator are more expensive. A new compressor including labour costs between 400 and 800 euros. Replacing a condenser costs on average 300 to 600 euros, depending on the model and how accessible it is. The evaporator is often located behind the dashboard and is therefore labour-intensive to replace. This location pushes the costs up to 600 to 1,000 euros.
Preventive maintenance is cheaper than repairs afterwards. By using the air conditioning regularly, even in winter, the seals remain supple and you prevent the system from seizing up. An annual check and topping up the refrigerant in good time helps to prevent expensive faults.
Practical tips to prevent aircon faults
Use the air conditioning all year round, even when it is cold outside. This keeps the system active and prevents rubber seals from drying out and cracking. Switch the aircon on at least once a month, even in winter.
Replace the cabin filter, the interior filter that cleans the air in the car, regularly. Ideally do this once a year or every 15,000 kilometres. A clogged filter puts unnecessary strain on the system and reduces cooling performance. This is a simple job that you can do yourself or have done during a service.
Watch out for signs such as reduced cooling, strange smells or unusual noises. The earlier you recognise a problem, the smaller the chance of costly damage. If in doubt, it is sensible to have a professional inspection carried out before a small issue grows into a major fault.
‘ Whether you are looking for advice on faults, experiences with specific models or practical guides, there is always something that matches your interests. ’
Discover more about car technology on Carnews
On the Carnews website you will find much more information about common car problems, maintenance tips and technical background information. Whether you are looking for advice on faults, experiences with specific models or practical guides, there is always something that matches your interests. Discover more and stay up to date with everything to do with cars.
Frequently asked questions
Typical symptoms are: the air no longer becomes cold or warm, the temperature fluctuates constantly, the blower does not respond to the selected setting or the aircon only works sometimes. Possible causes include too little refrigerant due to a leak, a defective (interior or exterior temperature) sensor, problems with the compressor or compressor clutch, or electrical faults such as a blown fuse, relay, wiring, or defective pressure or temperature switch.
Yes, a defective air conditioning system can affect both performance and fuel consumption, especially if the compressor seizes or runs heavily; the engine then has to deliver extra power, which is noticeable during sporty driving. If the aircon simply no longer switches on (compressor off), consumption will drop slightly and you will not notice any loss of engine power. A partly defective system (e.g. a grinding bearing or dragging compressor) can actually create extra resistance and thus adversely affect both performance and consumption. If in doubt, have the compressor and the drive (multi-rib belt, tensioner pulleys) checked specifically.
Have the aircon checked preventively at least once a year for refrigerant level and leaks (preferably with UV leak detection) and replace defective sensors, fuses and relays in good time. Use the air conditioning regularly, including in winter, so that the compressor and seals remain lubricated and age more slowly. Make sure the condenser and air ducts are free of dirt and leaves so that cooling remains efficient and the system pressure does not rise unnecessarily. If cooling fluctuates or fails, immediately have the pressure switches, interior temperature sensor and compressor clutch tested to prevent greater and more expensive consequential damage.
You can usually deal with a minor fault yourself if it concerns simple things such as checking fuses, using the settings correctly (AUTO, temperature, air distribution) and cleaning or replacing the interior filter. If the aircon continues to cool poorly or not at all, cuts out after some time, you hear unusual noises or see traces of leakage around pipes or compressor, it is wise to call in a specialist straight away. In the case of fluctuating operation (sometimes it works, sometimes it doesn’t), fault codes in the system or suspected sensor or compressor faults, professional diagnostics are required. If you are unsure whether it is safe to keep driving or to keep searching yourself, stop experimenting and go to an aircon specialist or garage.
Yes, with older or classic cars there are specific points of attention for the climate control system. Many of these cars have simple or outdated aircon systems that are more sensitive to leaks, wear of the compressor and problems with sensors or electrical connections. Parts can be harder to obtain and the system is often not designed for modern refrigerants, which makes maintenance more complex. Temperature control is also generally less precise than in modern vehicles with advanced climate control.
